(59)4 Series Mini Split 36k Btu/h 21 SEER Condensing Unit with 3x9k Btu Wall Mount Indoor Units
Product details
| Management number | 208501993 | Release Date | 2026/03/22 | List Price | $36.00 | Model Number | 208501993 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The YMGI 36CH(59)4 DC Inverter Outdoor Unit is a 36k Btu heat pump system that provides quiet, precise and efficient temperature control for 3 room applications. The system comes with three 9k wall mounted indoor units. This 3 Zone outdoor condensing unit has an 21 SEER rating. The system requires a 208-230 volt, 1 phase, 60Hz power. 40A Circuit Breaker required. The compact outdoor unit allows for ground installation, or mounting on a wall, under a deck, on a flat roof, or on a balcony. What's Included Outdoor condenser Qty:1 Indoor unit : 9k Wall Mount Unit Qty: 3 Remote Controls Qty: 3 Installation Lineset included Features 220V System AHRI certified with trusted quality World class compressor with great stability 21 SEER Efficiency and variable speed DC inverter Technology R410A refrigerant pre-charged Remote controller for each indoor unit Low Ambient cooling -4 F for Heating 0 F for Cooling Digital LCD display, Turbo mode, 3 fan speeds Auto level swing louver, Wide angle air distribution, Auto Restart Super Quiet Operation for good night sleep Auto Restart for sudden power cut and return Cleanable air filter Auto Start with Power failure recovery Self-diagnosis and Auto-Protection Function Wall Mount Unit Dimensions (Inch): 33.4 x 11.4 x 8.2 Installation Copper line set Size: 1/4"-3/8" BTUs Guide: 12,000 BTU for 500- 550 SQFt Please have your area inspected by HVAC technician and load calculation to be performed to determine if this system will be suitable to you, interior factor such as windows, ceiling height and insulation will affect cooling and heating result. Warranty YMGI offer 7 years on compressor and 2 year on other parts Please Note: Mini Split Systems must be installed by a licensed contractor with an EPA Refrigerant Certification to qualify for warranty. We are able to customize indoor and outdoor unit. If you require a different size for indoor or outdoor unit please contact our customer support
- 21 SEER Heat Pump
- Three Zones
- 36k Btu Heating and Cooling
- Three 9k Btu Wall Mount Indoor Units w Remote Control
- Precharged with refrigerant
- 2 Year Parts, 7 Year Compresser Warranty
- Includes 2 x 25' Copper Line sets and Wires
| Noise | 47 dB |
|---|---|
| Voltage | 220 Volts |
| Capacity | 3 Tons |
| Brand Name | YMGI |
| Model Info | WMMS-36CH-V2B(59)4-3x09kEW |
| Item Weight | 153 pounds |
| Part Number | WMMS-36CH-V2B(59)4-3x09kEW |
| Special Features | 4 Way Swing, Fast Cooling, Heating And Cooling Function, Inverter Compressor, Remote Controlled |
| Installation Type | Split System |
| Item model number | WMMS-36CH-V2B(59)4-3x09kEW |
| Product Dimensions | 13.4 x 38.6 x 31.1 inches |
| Included Components | 36k Btu Outdoor Unit, (3) 9k Indoor Wall Mount Units, 3 linesets, wires, free shipping |
